VXinspect
3D Inspection Software for Article Inspection & Quality Control
Creaform VXinspect is an intuitive and powerful 3D inspection software module designed for manufacturing companies conducting first article inspection (FAI) or quality control. VXinspect provides the simplest integration of probing, 3D scanning and photogrammetry measurements.
VXInspect is an intuitive and powerful 3D inspection software designed for first article inspection (FAI) and production quality control. Directly integrated into Vxelements, it provides the simplest integration of probing, 3D scanning and photogrammetry measurements into quality control workflows. Whether for performing part-to-CAD inspection or to build an entire inspection program, its intuitive interface is the best solution for all inspection workflows, with no compromises made on measurement quality and GD&T requirements. VXinspect is available in two versions, depending on your type of work and workflow. VXinspect is a user-friendly software for scan data inspections that streamlines single part root cause analyses. VXinspect|Elite is a complete inspection and dimensional analysis software for advanced quality control applications.
Benefits
VXinspect supports CAD import, allowing direct measurement comparisons with CAD models to better understand part manufacturing defects.
- .IGES
- .STEP
VXinspect is the first software to seamlessly integrate photogrammetry, single‑point touch probe and non-contact measurement (scan) into one unique and intuitive software interface.
- Photogrammetry
- Probing
- 3D Scanning
- Mesh import
Before starting the dimensional inspection process, the position and orientation of the object in space are of the utmost importance. Aligning the part leads to more accurate results throughout the process, from data acquisition up to the final inspection report.
- Entity selection
- Best fit
- Datum
- RPS (Reference Points System)
VXinspect sophisticated algorithms and calculation methods offer an accessible way to apply GD&T practices and principles to the inspection project, even for users without extensive experience in GD&T notions.
- Form and orientation tolerance
- Profile and localization tolerance
- Datum Reference Frame (DRF) construction using geometric counterparts
Inspection & Quality Control Applications
VXinspect covers all your FAI or production control needs
- Part-to-CAD analysis
- Conformity assessment of 3D models against original parts/production tooling
- Tool & Jig Verification
- Alignment
- First article and supplier quality inspection
- Conformity assessment of manufactured parts against the originals/golden part
- Maintenance
- Deformation monitoring
