HandySCAN 3D | Silver Series

Professional 3D scanning at an accessible price

The Silver Series is part of the HandySCAN 3D line-up, the industry standard in portable metrology-grade 3D scanners. This proven and trusted patented technology captures accurate and repeatable 3D measurements of any complex surface in any location.

When accuracy meets versatility and portability

The HandySCAN 3D | Silver Series is optimised to meet the needs of technology innovators and engineering professionals looking for a powerful, accessible, and reliable way to improve product development, shorten time-to-market, and reduce development costs.

Accuracy up to 0.03mm

Large Scanning Area

Scan-to-Mesh in seconds

Patented Technology

Accurate, Reliable & High-Resolution 3D Measurements

The HandySCAN 3D delivers accurate, high-resolution and repeatable results, regardless of the measurement setup quality and no matter the user experience. Featuring dynamic referencing, both the scanner and part can move during measurement and still provide an accurate and high‑quality scan.

  • Accuracy 0.03 mm (0.0012 in)
  • Volumetric accuracy 0.020 + 0.060 mm/m (0.0008 in + 0.0007 in/ft)
  • High repeatability and traceable certificate.
  • High level of detail.

Proven and trusted technology

Offering the best value for money, the HandySCAN 3D | Silver Series represents a smart purchase because of its accessible price and high-quality performance. Designed and manufactured in America and with more than 5,000 users already, this proven and trusted technology demonstrates Creaform’s prioritisation of attentive service and reliability.

  • Best price / performance option
  • More than 5,000 users worldwide
  • Designed and manufactured in North America
  • Supported by a global team of engineers and technicians

Portability

Using triangulation on optical reflectors to determine its relative position to the part, this handheld 3D scanner is a stand-alone device that does not require a tripod or any external tracking device to operate. Compact enough to fit into a small suitcase, it can be brought anywhere and used in any environmental conditions without performance being affected.

  • Lightweight and small 0.85 kg (1.9 lb)
  • Self-positioning with dynamic referencing
  • On-the-go scanning – Use it in-house or on site
  • Quick Setup – Up and running in less than 2 minutes

Simplicity and Versatility

With its user-friendly interface and ergonomic design, this 3D measurement solution is easy to use and has a short learning curve regardless of the user’s experience or expertise level. Its versatility enables users to scan various objects no matter the part size, complexity, material, or color—all with the same device.

Looking for the portable 3D scanner that offers the most value for your money?

Our experts will find the perfect 3D measurement solution for your needs!

HandySCAN 3D Scanning Applications

With its user-friendly interface and ergonomic design, this 3D measurement solution is easy-to-use and has a short learning curve.
Its versatility gives the opportunity to scan various object sizes and surface types in real time – all with the same device.

Quality Control

• First article inspection (FAI)

• Part-to-CAD inspection

• Supplier quality inspection

CAD Design

• 3D Scan-to-CAD

• Reverse Engineering (Extracting design intent)

• Packaging design

Replacement/Recycling

• Reverse Engineering for developing replacement / restoration parts

• Planning of complex assemblies disassembly / dismantling

Tooling Design

• Reverse Engineering of casts, dies, molds, fixtures, jigs and patterns

• Update of CAD file to reflect as-built tooling measurements

• Tooling validation/Inspection

Assembly/Production

• Virtual Assembly

• Tool/Robot path programming

• Part assessment before machining

Prototyping

• Rapid prototyping / Manufacturing

• Integration of prototype modifications into CAD file

• Prototype inspection

Testing, Simulation & Analysis

• Finite element analysis (FEA)

• Interference analysis

• Deformation, geometry analysis

Requirements & Specifications

• Competitive product analysis

• Measurement of product environment or connecting/surrounding parts

• Measurement of existing parts for aftermarket or custom equipment

Concept Design

• Clay model measurement/Reverse Engineering

• Models & mock-ups measurement/Reverse Engineering

• Styling & aesthetics

Concept Prototyping

• Integration of prototype modifications into CAD file

• Form study, proof-of-concept prototypes

• Ergonomy prototypes

Documentation

• As-built documentation of parts / Tooling before maintenance

• Digital archiving, marketing presentations, 3D training systems, professional gaming

Maintenance, Repair & Overhaul

• Wear & Tear Analysis

• Custom repairs/Modification

• As-built documentation of parts / Tooling before maintenance

Technical Specifications

A brief look at technical specifications of this innovative technology that enables TRUaccuracy, TRUsimplicity, TRUportability, and speed for your metrology-grade applications.

Accuracy

Up to 0.03mm (0.0012 in)

Volumetric Accuracy

0.020 mm + 0.060 mm/m
(0.0008 in + 0.0007 in/ft)

Measurement Resolution

0.050 mm (0.0020 in)

Measurement Rate

480,000 measurements/s

Part size range (recommended)

0.1 – 4 m (0.3 - 13 ft)

HandySCAN 3D Software

The HandySCAN 3D comes with VXelements, which powers our entire suite of 3D scanning and measurement technologies. It combines all the essential tools you need from data acquisition to CAD Software, in a user-friendly, simplified and sleek working environment.

Software Modules

Dimensional inspection software module

Scan-to-CAD software module

Compatible Software

AESUB Blue - Subliminating 3D Scanning Spray

SPRAY | SCAN | DONE

  •  Disappearing state of the art scanning spray
  •  No cleaning required
  •  Thin and homogeneous coating
  •  Free of pigments
  •  Developed and approved by scanning experts

Ask our Experts

Professional CAD Systems is a Senior Creaform Partner. We offer the following services:

  • Software and Hardware Technical Support Helpline
  • Equipment Maintenance, Tuning and Calibration
  • 3D Scanner Fault Dagnosis and Basic Repairs
  • Creaform 3D Scanner Warranty Renewal
  • Creaform 3D Scanner Loaner Services

Request a Quote/More Info

request_quote
  • This field is for validation purposes and should be left unchanged.
Menu
Call Now Button

HandyScan Silver Scanner - System Requirements

  • Windows: 7, 8 or 10 (64-bit)
  • Dedicated Graphics Card with 4GB Memory (8GB+ Video Memory Recommended)
  • 2.6GHz+ Quad Core Processor (6+ Cores Recommended)
  • 16GB RAM (32GB+ Recommended)
  • 3-Button Scroll Wheel Mouse

WARNING: Integrated Intel Graphics found on many laptops & tablets are NOT SUPPORTED !!
