Enscape, overview

System Requirements

This page provides information about the system requirements for Enscape.

On this page
  1. Soft Support for CAD/BIM Software
  2. Windows OS
  3. Required CAD/BIM Software
  4. System Requirements
  5. macOS
  6. Required CAD/BIM Software
  7. System Requirements
  8. Recommended Graphics Drivers
  9. System Support

This page provides information about the system requirements for Enscape.

Soft Support for CAD/BIM Software

When a host CAD or BIM application releases a new version, Enscape adds support for it as soon as possible in an upcoming release. At that point, the oldest supported version moves out of official support. When a CAD or BIM version moves out of official support, it no longer receives bug fixes, testing, or compatibility guarantees. To give projects more flexibility during transitions, each version then enters a period of soft support, during which it remains available in the installer before its full removal.

Soft support means that Enscape continues to work on the affected CAD and BIM versions but does not receive bug fixes for them. Enscape also does not guarantee that new features are fully compatible with these host application versions.

The soft support period for each host application is as follows:

  • SketchUp: 1 year of soft support
  • Revit: 2 years of soft support
  • Rhino: 2 years of soft support
  • Archicad: 2 years of soft support
  • Vectorworks: 2 years of soft support

Windows OS

Enscape uses ray tracing for real-time rendering, and it handles almost all calculations on the graphics processing unit (GPU). Make sure your computer meets the minimum recommended system requirements listed below.

We recommend using Enscape with dual monitors, as it is optimised for a dual-monitor setup.

Required CAD/BIM Software

The Enscape for Windows plug-in is provided for the following host applications:

  • Revit 2024, 2025, 2026 and 2027
  • SketchUp 2024, 2025 and 2026 + preliminary support for SketchUp 2027 Beta
  • Rhino 7.0, 8.0, 8.2, 8.3 (or later)
  • Archicad 28, 29 and 30
  • Vectorworks 2025, 2026 and 2027 (including compatibility with its new OpenPBR material system)

On Windows, the Enscape plugin is installed by default for all of the above-listed host applications unless otherwise specified during installation. This means you don't need a dedicated installer for each host application, and you can specify which CAD or CADs you want to install Enscape for during installation.

Update your CAD application listed above to the latest software release or update available from the manufacturer to access all fixes and improvements.

System Requirements

Enscape renders using your graphics card (GPU). Both dedicated GPUs and the integrated GPUs listed on this page are supported. If your system's CPU and RAM can handle Revit, for instance, and you have a capable GPU, Enscape should work. A good CPU can speed up Enscape’s loading times. The system requirements for running Enscape and the Standalone Executable files that can be exported from Enscape are identical.

Use a cable connection instead of Wi-fi to ensure fast loading of the Asset Library.

Windows OS

Minimum Requirements

Recommended Requirements

VR Requirements

Windows OS

Minimum Requirements

Recommended Requirements

VR Requirements

Operating System

Windows 10 or higher

Windows 10 or higher

Windows 10 or higher

Dedicated GPU

4GB VRAM, supports Vulkan 1.2

  • NVIDIA GeForce GTX 10 series / Quadro P series and newer
  • AMD Radeon RX 5000 series / equivalent Radeon Pro series and newer
  • Intel Arc A310 and newer

8GB VRAM

NVIDIA GeForce RTX 3070 Ti or AMD RX 6800

12GB VRAM

NVIDIA GeForce RTX 4070 Ti or AMD RX 7900 XT

Integrated GPU

Machines without a dedicated GPU

  • Intel 13th Gen and newer
    Laptops: UHD Graphics 64EU iGPU and above
    Desktops: UHD 730 iGPU and above
  • AMD Ryzen 6000 series with Radeon 660M and above
    Ryzen 7000 series with Radeon 740M and above

—

Not supported

Graphics Drivers

The latest available drivers, or at least our recommended drivers.

VR Headsets

Meta Quest 3

HTC Vive Pro 2

Refer to the hardware requirements in our Virtual Reality Headset guide

Additional Software Requirements

The Enscape installer checks for additional software required to run Enscape. If that software is not present, the installer prompts you to download and install whatever is missing from your system.

For deploying Enscape via Command Line, here’s a list of the required software:

Hardware Limitations

  • Integrated GPUs: VR and hardware ray tracing are not supported.
  • NVIDIA GTX 1660, T1000 and T2000: DLSS and hardware-accelerated ray tracing are disabled since Enscape 4.0 due to performance issues. On earlier versions, we highly recommend disabling RTX for these GPUs.
  • Multiple GPUs / SLI: SLI is not supported. In the case of multiple GPUs, Enscape uses only one. Tip: SLI AFR mode (NVIDIA driver settings) can give a performance boost.
  • Docking stations: only docking stations that support accelerated graphics work with Enscape.

Known Issues

There are conflicts with two other Revit plugins: Colorizer and Techviz. To avoid incompatibilities, please uninstall them before using Enscape.

macOS

Enscape and its rendering engine rely heavily on the graphics processing unit (GPU) performance in the Apple Silicon chipset and the Mac's unified memory. To optimise this, your computer must meet the minimum recommended system requirements outlined below.

Furthermore, we recommend using Enscape in a multi-monitor setup to fully support the workflow between the CAD application and Enscape.

Required CAD/BIM Software

The Enscape for Mac plug-in is provided for the following host applications:

  • SketchUp 2024, 2025 and 2026 + preliminary support for SketchUp 2027 Beta
  • Rhino 7.0, 8.0, 8.2, 8.3 (or later)
  • Archicad 28, 29 and 30
  • Vectorworks 2025, 2026, and 2027 (including compatibility with its new OpenPBR material system)

On macOS, the Enscape plugin is installed by default for all the above-listed host applications, unless specified otherwise during installation. This means you don't need a dedicated installer for each host application, and you can specify which CAD or CADs you want to install Enscape for during installation.

We recommend updating your CAD application listed above to the latest software release or update available from the manufacturer to ensure you have all fixes and improvements.

System Requirements

Enscape performs its renders using your graphics card (GPU).
A good CPU can speed up Enscape’s loading times.

We also recommend a fast, stable internet connection, a direct cable connection, and avoiding Wi-Fi where possible, as these can slow Asset Library loading times.

macOS

Minimum Requirements

Recommended Requirements

VR Requirements

macOS

Minimum Requirements

Recommended Requirements

VR Requirements

Operating System

macOS 14.8.1 (Sonoma)

Apple M1

MacBook Air (2020)

MacBook Pro (2021)

iMac (2021)

Mac mini (2020)

MacBook Pro (M1 Pro/Max, 2021, 32 GB of Unified Memory)

Mac Studio (M1 Max/Ultra, 2022, 32 GB of Unified Memory)

Apple M2

MacBook Air (2022/2023)

MacBook Pro (2022)

Mac mini (2022)

MacBook Pro (M2 Pro/Max, 2023, 32 GB of Unified Memory)

Mac Pro (M2 Ultra, 2023, 64 GB of Unified Memory)

Mac Studio (M2 Max/Ultra, 2023, 32 GB of Unified Memory)

Mac mini (M2 Pro, 2022, 32 GB of Unified Memory)

Apple M3

MacBook Air (2024)

MacBook Pro (2023)

iMac (2023)

MacBook Pro (M3 Pro/Max, 2023, 36 GB of Unified Memory)

iMac (M3, 2023, 24 GB of Unified Memory)

Apple M4

MacBook Air (2024)

Mac mini (2024)

iMac (2024)

MacBook Pro (2024)

Mac mini (M4 Pro, 2024, 48 GB of Unified Memory)

iMac (M4, 2024, 24 GB of Unified Memory)

MacBook Pro (M4 Pro/Max, 2024, 48 GB of Unified Memory)

Apple M5

MacBook Air (2025)

MacBook Pro (2025)

MacBook Pro (M5 Pro/Max, 2025, 48 GB of Unified Memory)

Unsupported:

Unsupported:

Macs with Intel CPU and Intel or AMD GPU

Driver updates are supplied by Apple exclusively via updates to the operating system macOS itself. We therefore encourage you to update macOS to the latest version your software situation allows.

System Support

If you run into trouble, let us know by using Enscape’s Feedback function or contact our support.
